Quick Overview
Foldable Stand. Total Arm Length: 250mm. Illumination Type: LED Reflection Light. Light Adjustable. Optical Lens Diopter: 3/10 Diopter (1.75/3.5X). Lens Size: Dia. 130mm (5.1 in. )/ Dia. 26mm (1 in. ). Minimum Unit:mm/inch.
MG02201111 3/10D LED Magnifying Lamp (Desktop)
Power Supply
| Battery | AAA (Included Four Batteries) |
Magnifying Lamps
| Stand Type | Foldable Stand |
| Stand Height | 250mm |
| Total Arm Length | 250mm |
| Base Type | Table Base |
| Base Shape | Round |
| Illumination Type | LED Reflection Light |
| LED Quantity | 2 |
| Power Supply Adjustable | Light Adjustable |
| Bulb Color (Wavelength) | White Light |
| Optical Lens Diopter | 3/10 Diopter (1.75/3.5X) |
| Lens Size | Dia. 130mm (5.1 in. )/ Dia. 26mm (1 in. ) |
| Lens Type | Convex |
| Magnifier Lens Material | Glass |
| Head Size | Dia. 157mm (6.181 in. ) |
| Head Material | Plastic |
| Head Appearance | Round |
| Head with Handle | No |
| With Lens Shield | No |
| %Bigger Than Object | 75% |
| Swing Arm Material | Metal |
| Base Material | Plastic |
| Notes | Minimum Unit:mm/inch |
Other Parameters
| Surface Treatment | Plastic Spray Coating |
| Color | White |
| Net Weight | 0.37kg (0.82lbs) |
Technical Info
Instructions
Light AdjustableClose Λ
| The brightness of the light source adjustable is very important in the imaging of the microscope. Since the difference of the numerical aperture of the objective lens of high magnification and low magnification is very big, more incident light is needed to achieve a much better resolution when using a high magnification objective lens. Therefore, when observing through a high magnification objective lens, the brightness required is high; when observing through a low magnification objective lens, the brightness required is low. When observing different objects, or feature points of the same object at different positions, the brightness needs are also different; including the difference of background light or reflection within the field of view of observation, it has a great influence on the effect of observing the object, and therefore one needs to adjust the brightness of the light source according to each object to be observed. In the light source capable of providing continuous spectrum, such as a halogen lamp, the brightness adjustment of the light not only adjusts the brightness and intensity of the light, but also changes the spectrum emitted by the light source. When the light source is dark, there are many components of red light, and when the brightness is high, there are more blue spectrum. If the required light is strong and the spectrum needs to be changed, the light can be kept at a brighter intensity, which is solved by adjusting the spectrum by adding a color filter. Take note of the dimming button on the light source, after the On/Off switch is turned on, normally clockwise is to brighten, and counterclockwise is to darken. If it is adjusted to the lowest brightness, the light source should normally be lit. If the naked eye still can't see the object being illuminated brightly, you need to adjust the brightness knob to a much bigger position. Generally, there is scale marking on the dimming knob, which is an imaginary number representing the percentage of brightness, or an electronic digital display, giving the brightness of the light source under the same conditions a marking. |
PackagingClose Λ
| After unpacking, carefully inspect the various random accessories and parts in the package to avoid omissions. In order to save space and ensure safety of components, some components will be placed outside the inner packaging box, so be careful of their inspection. For special packaging, it is generally after opening the box, all packaging boxes, protective foam, plastic bags should be kept for a period of time. If there is a problem during the return period, you can return or exchange the original. After the return period (usually 10-30 days, according to the manufacturer’s Instruction of Terms of Service), these packaging boxes may be disposed of if there is no problem. |
| Packing | |
| Packaging Type | Carton Packaging |
| Packaging Material | Cardboard Box |
| Packaging Dimensions(1) | 16.5x32x5.7cm (6.496x12.598x2.244″) |
| Inner Packing Material | Plastic Bag |
| Ancillary Packaging Materials | Styrofoam |
| Gross Weight | 0.45kg (0.99lbs) |
| Minimum Packaging Quantity | 1pc |
| Transportation Carton | Carton Packaging |
| Transportation Carton Material | Cardboard Box |
| Transportation Carton Dimensions(1) | 16.5x32x5.7cm (6.496x12.598x2.244″) |
| Total Gross Weight of Transportation(kilogram) | 0.45 |
| Total Gross Weight of Transportation(pound) | 0.99 |
| Quantity of One Transportation Carton | 1pc |
  |
